00-C-2763
and be ready for full load operation within 15 minutes in any ambient
temperature from +120 degrees Fahrenheit (oF) to -20°F. When a fluid priming
system is required, it shall be of the measured shot type with storage capacity
of at least 12 fluid ounces. The engine(s) shall be furnished complete with at
least the following accessories:
a.
An instrument panel complete with a lubricating oil pressure gage,
a fuel oil gage, a cooling liquid-temperature inicator, a
voltmeter or ammeter, a tachometer, an hour meter (may be located
in engine compartment), and a speedometer with recording odometer.
b.
Fuel tank(s) with sufficient capacity for 8 hours normal operation.
c.
12V or 24V electric cranking system.
d.
When specified (see 6.1) battery(s) shall be dry charged in
accordance with Federal Specification W-B-131, without electrolyte,
with sealed caps to prevent the intrusion of atmospheric moisture.
e.
Charging alternator(s) with a capacity rating compatible to the
system.
f.
Cooling-liquid high temperature safety device of the warning type.
Lubricating oil safety device.
g.
h.
Fuel oil level gage.
i.
An engine housing so designed as to facilitate the maintenance of
engine.
`Transmission temperature gage {automatic transmission only).
j.
3.13.6 Outriggers. Not less than four hydraulically powered outriggers,
capable of being extended not less than 3 inches below ground level, shall be
furnished. The outriggers shall have sufficient strength to accept full
stability, under all rated loading conditions, including the ability to raise
the truck cranes off the ground from travel position, when necessary to
compensate for ground surfaces having irregular contours. Vertical outrigger
cylinders shall have check valves as a part of or attached to the cylinder.
Horizontally extended, hydraulic cylinders shall be enclosed within outrigger
boxes . Outriggers in the stowed position, ready for travel, shall not exceed
maximum allowable overall width. Devices to accurately determine when the
cranes are level shall be installed in a position convenient to the outrigger
controls. All hydraulic hoses shall be enclosed or routed to preclude external
damage. A front mounted outrigger shall be furnished on all cranes 30 tons and
larger.
3.14 Attacments. The following attachments in type and size shall be
furnished as specified (see 6.1):
Clamshell bucket and tagline.
Towing hook.
c. Towing winch.
3.15 Radio no ise suppre ssors. When specified (see 6.1), the crane shall be
equipped with radio noise suppressors. Electro-magnetic radiation from the
crane shall be within the limits of SAE J551.
3.16 Lifting and tiedown attachments. The crane shall be equipped with
lifting and tiedown attachments. Lifting and tiedown attachments shall conform
to-type II or type III of MIL-STD-209. A nonferrous transportation plate shall
be provided and mechanically attached to the crane. Transportation plates shall
9
